Making simple applications, simple.
Take charge of motor control and energy savings with the latest addition to the Control Techniques portfolio. With a feature set optimised for simple applications, Commander S provides a cost-effective solution for installations that require plug and play convenience straight from the box.
Commander S is the first drive to come with an app interface as a standard feature. The Marshal app is our revolutionary way to interface with the drive covering commissioning, monitoring, diagnostics and support.
Marshal: your drive expert in the field
Revolutionise the way you interface with your drive
Control Techniques has a long tradition of challenging the status-quo with innovative ideas and making a profound impact in the drives industry. And we've done it again with Marshal: Control Techniques is the 1st drive supplier to implement NFC technology as standard on a drive and offer the Marshal app interface at no extra cost.
Marshal is your drive expert in the field. This rich content interface means you can commission, clone, diagnose system issues and monitor the drive in just a few screen taps.
Want to know more about Marshal? Click here.
Benefits
 |
Easy to install The sleek curved design of Commander S optimises component layout for a small footprint and easy access to terminals. The click-on/click-off DIN rail mount makes installation remarkably easy. |
 |
Easy to use Using our new Marshal app (Android/iOS) your drive can be configured in under 60 seconds. |
 |
Reliable Durability is at the core of Commander S design, guaranteeing performance throughout its whole lifetime. |
 |
Cost effective Equipped with unique features designed to save you time, energy and money. |
Applications
 |
Fan, pump, compressor applications Improved energy efficiency during periods of low demand
|
 |
Moving applications Conveyors, Treadmills, Automatic Doors & Barriers
|
 |
Processing applications
|
Software
 |
Connect - intuitive commissioning software Connect is our latest drive configuration tool for commissioning, optimising and monitoring drive/system performance. |
3D CAD Models
 |
Commander S 3D CAD Models Detailed product specifications, datasheets and 3D CAD models based on your configuration. |
This product comes with 5-year warranty as standard
No registration. No extra cost. Just peace of mind from day one. Learn more.
Power & Control
| Voltage | 1Φ AC 100 & 200 V 3Φ AC 200 & 400 V |
| Power Range | 0.18 to 4 kW / 0.25 to 5 hp |
| Duty Rating | Heavy Duty |
| Input Frequency | 50/60 Hz |
| Output Frequency | 0 to 300 Hz |
| Switching Frequency | 4 kHz and 12 kHz |
| Motor Control | Linear V to F, Square V to F, Resistance, Compensation |
| Stopping Modes | Coast, Ramp, Ramp & DC Injection Braking, DC Braking with 0 Hz detect, Timed DC Braking, Distance Stop |
| Communications | RJ45 for Modbus RTU NFC for app interface |
Inputs & outputs
| Analogue | 2 x Analogue inputs 1 x Analogue output |
| Digital | 4 x Digital inputs 1 x Digital input / output |
| Relay | 1 x Relay (single pole, double throw relay) |
Standards
| Approvals | CE, UKCA, cUL, C-Tick, EAC, KC |
| Product Safety Standards |
IEC/EN/KN/UL 61800-5-1, CSA C22.2 No.274, GB12668.501-2013 |
| Emission Compliance |
C3 internal EMC filters C1 & C2 with external EMC filters C1 internal EMC filters, for selected 1Φ 200 V variants |
Mounting & environment
| IP Rating | IP20 |
| Mounting | Click on/click off DIN rail mount Screw mount 0 mm side by side |
| Ambient Temperature |
Operation without de-rate: -10°C to 40°C (14°F to 104°F) Operation with de-rate: -10°C to 60°C (14°F to 140°F) Storage: -40°C to 60°C (-40°F to 140°F) |
The Commander S series provides energy-efficient motor control for a wide range of industries:
Its compact design, integrated features, and app-based commissioning make it one of the most user-friendly drives available. Whether it’s for OEMs or standalone use, Commander S delivers dependable performance and reduced installation time.
Remote Interface
 |
Remote Keypad IP66 Remote mountable, intuitive plain text, multilingual LCD keypad for rapid setup and helpful diagnostics from the outside of a panel. Meets IP66 (NEMA 4). |
 |
HMI The MCh panels and MChMobile Software have been designed for the easy development of HMI applications including factory and building automation. |
Optional extras
 |
Terminal Cover Commander S has a terminal cover fitted as standard. These are also available as a spare. |
 |
Cable Management Bracket Use of the optional cable management bracket allows the wiring cables to be neatly secured under the drive. |
 |
Fibre Filter The optional fibre filter allows the drive to operate efficiently even in environments prone to airborne fibres (e.g.: textile applications). Filter cleaning can be incorporated into the preventative maintenance cycle, lowering the risk of an unplanned outage. |
 |
RS485 Cable The USB comms cable allows the drive to connect to a PC for use with Commander's PC tools. |
